| Suggested retail price |
$4198 |
$3669 |
| Warranty |
6 months, 6000 miles |
12 months, unlimited mileage |
| Number of U.S. dealers |
1787 |
1450 |
| Cost of shop manual |
$14.60 |
None available |
| ENGINE |
|
|
| Type |
Four-stroke DOHC six |
Four-stroke DOHC four |
| Displacement |
1047cc |
1075cc |
| Bore . stroke |
64.5 x 53.4mm |
72 x 66mm |
| Compression |
9.3:1 |
9.5:1 |
| Carburetion |
6, 28mm Keihin CV |
4, 34mm Mikuni CV |
| Ignition |
Transistorized pointless |
Transistorized pointless |
| Lubrication |
Wet sump, trochoidal pump |
Wet sump, trochoidal pump |
| Lighting output |
350 watts |
230 watts |
| Battery |
12V, 18AH |
12V, 14AH |
| DRIVETRAIN |
|
|
| Primary transmission |
Hy-Vo chain/jackshaft,2.27:1 |
Spur gear, 1.775:1 |
| Clutch |
13 plates, wet |
18 plates, wet |
| Final drive |
5/8 x 3/8 (No. 530) RK endless chain, 42/18, 2.33:1 |
3/4 x 3/8 (No. 630) D.I.D. endless chain, 42/15, 2.8:1 |
| CHASSIS |
|
|
| Fork |
35mm Showa, 6.3 in. travel
| 37mm Kayaba, 7.9 in. travel |
| Shocks |
Showa, 3.9 in. wheel travel |
Kayaba, 4.25 in. wheel travel |
| Front tire |
3.50-19 Dunlop Gold Seal F11 4.25-18 |
3.50-19 Bridgestone Mag Mopus L303 |
| Rear tire |
Dunlop Gold Seal K127 |
4.50-17 Bridgestone Mag Mopus
| Rake/trail |
27.5'/4.7 in. (119mm) |
28'/4.06 in. (103mm) |
| Wheelbase |
59.0 in. (150mm) |
61.0 in. (1549mm) |
| Seat height |
32.0 in. (813mm) |
31.75 in. (806mm) |
| Ground clearance |
7.0 in. (178mm) |
6.0 in. (152mm) |
| Fuel capacity |
5.3 gal. (20 liters) |
5.0 gal. (19 liters) |
| Wet weight |
611 lbs. (277kg) |
560 lbs. (254kg) |
| GVWR |
1055 lbs. (479kg) |
1030 lbs. (467kg) |
| Colors |
Black, red |
Silver, metallic red |
| Instruments |
Speedo, odometer, tach, resettable tripmeter and indicator lights for high beam, neutral, turn
signals and low oil pressure |
Speedo, odometer, tach, fuel gauge, resettable trip meter, indicator lights for neutral, high
beam, turn signals and low oil pressure. Check panel for, headlamp, battery, taillamp stop lamp
and low brake fluid. |
| PERFORMANCE |
|
|
| Power to weight ratio, unladen |
8.4 lbs./hp |
6.5 lbs./hp |
| Fuel consumption |
29 to 41 mpg, 35.1 mpg average |
36 to 45 mpg, 41.9 mpg average |
| Average touring range |
186 miles |
210 miles |
| Quarter-mile |
11.84 sec. at 116.1 mph |
11.34 sec. at 118.9 mph 3800 |
| RPM at 60 mph in top gear |
4400 |
| Speed in gears at (redline) |
(9500) lst 56 mph;2nd 79 mph; 3rd 99 mph; 4th 115 mph; 5th 133 mph |
(9000) lst 54 mph;
2nd 76 mph; 3rd 98 mph; 4th 120 mph; 5th 141 mph |
| Speedometer error |
30 mph, actual 30; 60 mph, actual 60 |
30 mph, actual 29; 60 mph, actual 58 |
|
